Wall Type Indicator Post

The Wall Type Indicator Post (Models MH-1510FA/MH-1510A) is a UL/FM-approved wall-mounted fire hydrant system, designed for reliable water supply in commercial, industrial, and urban public spaces—supporting fire truck and hose connection for efficient fire suppression.

Material :
Ductile Cast Iron
Inlet :
6" (DN150)
Working Pressure :
10 bar (145 PSI)
Type :
Wall Type Indicator Post
MOQ :
20 Pieces
Delivery Time :
15~30 Days

Email : jony@jyfire.com.cn

Inquiry now Chat Now!

Product Description

The Wall Type Indicator Post (MH-1510FA/MH-1510A) is a high-performance wall-mounted fire safety device, engineered to deliver stable, high-pressure water flow for fire suppression. Compliant with AWWA C502 standards and UL/FM approved, it features a durable ductile iron + metal component construction, with red polyurethane (or custom) painting for high visibility.

Equipped with a 6" (DN150) inlet flange and multi-nozzle configuration (1×4.5" pumper nozzle + 2×2.5" hose nozzles), this post supports simultaneous connection of fire trucks and hoses. It includes a dedicated hydrant wrench for operation, and its sealed design + drainage system ensures long-term reliability in outdoor environments. Available in flange (MH-1510FA) or mechanical (MH-1510A) connector options, it adapts to different pipeline installation needs.

Features

UL/FM Approved: Meets global fire safety standards (UL 246, FM 1510) for reliable performance.
Multi-Nozzle Configuration: 1×4.5" pumper nozzle + 2×2.5" hose nozzles for flexible fire-fighting operations.
Dual Connector Options: Flange (ASME B16.5 CLASS 150/DIN 2501 PN16) or mechanical (AWWA/ANSI C153) for pipeline compatibility.
High Durability: Ductile iron body + 316 stainless steel/steel 1045 components resist corrosion and impact.
Visibility & Customization: Red polyurethane + bitumen black painting (custom colors available) for quick emergency identification.
Integrated Drainage: Spring-loaded drain hole ensures residual water discharge to prevent freezing/damage.

Products Parameter

Material	Ductile Cast Iron
Inlet Size	6" (DN150)
Main Valve Size	133.4 mm (5-1/4")
Nozzles	1×4.5" (4NH thread) pumper nozzle; 2×2.5" (7.5NH thread) hose nozzles
Connector Options	Flange: ASME B16.5 CLASS 150/DIN 2501 PN16; Mechanical: AWWA/ANSI C153
Nominal Pressure	250 PSI
Working Pressure	10 bar (145 PSI)
Testing Pressure	24 bar (348 PSI)
Buried Dimensions (mm)	1063 (3'6"), 1215 (4'), 1368 (4'6"), 1520 (5'), 1673 (5'6"), 1825 (6"), 1978 (6'6"), 2130 (7')

Q: Can the connecting coupling be customized?

A: Yes, we support custom coupling types to match local pipeline standards.

Q：What is your payment terms？

A：Payment supports T/T, L/C, etc. We also support payment via wechat or Alipay.

Q: Is this hydrant suitable for cold regions?

A: Yes—we provide frost-proof versions for cold climates (please specify your region when ordering).

Q: Can the water outlet size be customized?

A: Yes, we support custom outlet sizes to match local fire hose standards.
